250kgs per human resources capacity waste incinerator

Burner Design TS250 PLC, Review

This design is small waste incineration tools for little waste result. Construction

Items/Model	TS200( PLC)
Principle	Solid Waste Incineration Therapy
Melt Price	Average 250 kg/hour
Feed Ability	Requirement 350kg/feeding
Control Establishing	PLC( Programmable Logic Controller Burner)
Burning Chamber	1800L
Internal Measurements	150x110x110cm
Second Chamber	750L
Smoke Filter Chamber	Yes
Feed Mode	Handbook
Voltage	220V
Power	0.9 Kw
Oil Intake (kg/hour)	Common 28
Gas Usage (m3/hour)	Typical 33.6
Temperature Level Display	Digital Existing
Temperature Level Degree Security	Yes
Oil Tank	300L
Feed Door	80x60cm
Smokeshaft	10Meter
Smokeshaft Kind	Stainless-steel
1st. Chamber Temperature Level	800 ℃–– – – -1000 ℃
2nd. Chamber Temperature Level	1000 ℃ -1200 ℃
Residency Time	2.0 Sec.
Gross Weight	8500kg
Exterior Dimensions	300x160x190cm

Heater procedure should certainly be Automatic On/Off

Gas: diesel

The supplier need to supply needed details for the very best of the installment

This burner with “PYROLYTIC” burning need to have:

;

・ Refractory concrete:

§. Thickness: ≥ 100 mm

§. Nature: 42% of Al203

・ Guard in coarse panels:

§. Thickness: ≥ 75 mm

・ Nature: Calcium silicate.

* Heater of illumination of waste, with gas, typical mono-bloc casting directing diving flame, lights and additionally safety and security of digital ignition, permanent air circulation, electro-magnetic sluice entry of guideline in addition to isolating valve.

* Plate of burning in Carborundum, staying clear of the taking care of glass along with slags.

A chamber of short article burning of gases

* A heating system of burning of gases,

* A gadget of shot of air making it possible for a total recombustion of gases,

* A device of air inlet of air conditioning of waste gases,

* A sheath of clearing of the gases charred.

* Carcass in solid sheet steel with assistance of web link.

* Structure of the refractory;

・ Refractory concrete:

§ Thickness: ≥ 150 mm

§ Nature: 65% of Al203

・ Protect in rugged panel:

§ Thickness: ≥ 85 mm

Nature: Calcium
